Technical parameters:

1. Overall dimension (mm): 755x755x467

2. Air flow (m) 3/ h）：4300

3. Heat: 39KW

4. Air inlet temperature: 15 ℃

5. Air outlet temperature: 44 ℃

6. Electric power: 0.31kw

7. Weight: 90kg

8. Windward area: 0.47 ㎡

9. Heat dissipation area: 21.46 ㎡

10. Number of finned tubes: 26

11. Outlet wind speed: 3.11m/s

12. Water consumption: 1690kg / h, water flow rate: 0.91m/s, water resistance: 11kpa

13. Noise: 65dB (a)

14. Inlet and outlet pipe: R1 "1 / 4"

15. Inlet water temperature: 90 ℃, return water temperature: 70 ℃
